In hazardous areas such as oil refineries, chemical plants, gas stations, and flour silos where flammable gas, vapor, or dust is mixed into the working atmosphere, Exproof Lighting systems are the primary line of defense for occupational safety. Standard LED luminaires cannot provide adequate protection here because a possible arc, spark, or excessive temperature can trigger an explosive mixture. Exproof Lighting luminaires are designed to eliminate this danger with working temperature control, flameproof housing construction, and certified cable routing.
Explosive Atmosphere Classification
According to the IEC/EN 60079 standard, luminaires to be used in Zones 1–2 (gas) and 21–22 (dust) must have ATEX or IECEx certification. The tamper-chip temperature category must be kept below the spontaneous ignition point of the ambient mixture; for example, a T6 class Exproof Lighting luminaire can safely operate in oil pipeline tunnels with a housing temperature not exceeding 85°C. In flour mills containing explosive dust, IP66/IK10 protection plays a critical role in terms of both cleanability and impact resistance.
Mechanical and Thermal Design
The housing is generally cast from marine-grade aluminum alloy; a stainless steel bolted flange, neoprene O-ring, and tempered glass complete the flameproof seal. 120 lm/W efficient mid-power LED chips are cooled by a dual-channel heat pipe system, guaranteeing a 60,000-hour L80 lifespan. A thermal fuse and NTC sensor automatically reduce the current in over-temperature scenarios, thus eliminating the fire risk in Exproof Lighting fixtures.
Electrical Safety and Intelligent Control
Drivers with PF ≥ 0.95 and THD ≤ 10% parameters minimize harmonic distortion and prevent failure of sensitive equipment in the factory network. A 6 kV integrated surge arrester module dampens voltage spikes in refinery sites where lightning strikes are frequent. The DALI-2 compliant variant saves energy by automatically reducing the luminaire current based on signals from explosive atmosphere sensors (H₂S, methane, VOC, etc.); moreover, this process is safely carried out via certified Ex d cable glands.
Ease of Installation and Maintenance
The Ex d boxed terminal chamber locks the terminal inside at the automatic opening point when the cover is opened; maintenance technicians can check cable tightness without interrupting the power. A single stainless steel hanging hook allows for quick installation on a chain or pipe system. The diffuser front surface is tempered glass with an antistatic coating, preventing dust particles from adhering to the surface and maintaining light transmission.
Sustainability and Certification
The housing, with over 90% recycled aluminum, reinforces the environmentally friendly approach with the use of lead-free solder and halogen-free cable. Classified as Group 0 according to the EN 62471 photobiological test, it offers light output that does not risk personnel eye health.
By combining these high-level safety and performance components on a single platform, Ossam Lighting minimizes the risk of explosions in industrial facilities with its ATEX Zone 1 & Zone 21 certified product range. Thanks to the remote monitoring panel, LED temperature, brightness degradation, and energy consumption are reported in real time; thus, Ossam Lighting's Exproof Lighting solutions guarantee reliable, long-lasting, and sustainable lighting in your critical areas.
